Open Frame Power Supply
2" x 4", 3" x 5" standard form factors are available for selection. Modified standard and custom designs are welcome.
- Class-I design 420W dual outputs
- 12V @ 50W, 54V @ 370W
- For PoE application
- Dimension 4"x7.5"x1.244"
- Isolated between 12V & 54V outputs
- Isolated between PE & RETURN
- Class-I design 350W @ 54V
- Designed to meet IEC 60950-1 & IEC 62368-1
- Dimensions 3 x 5 x 1.34 inch
- No load power consumption less than 0.5W
- Class-I design 350W @ 24V
- Designed to meet IEC 60950-1 & IEC 62368-1
- Dimensions 3 x 5 x 1.34 inch
- No load power consumption less than 0.5W
- Class-I design 350W @ 18V
- Designed to meet IEC 60950-1 & IEC 62368-1
- Dimensions 3 x 5 x 1.34 inch
- No load power consumption less than 0.5W
- Class-I design 350W @ 12V
- Designed to meet IEC 60950-1 & IEC 62368-1
- Dimensions 3 x 5 x 1.34 inch
- No load power consumption less than 0.5W
- Class-I design 300W @ 24V with +5Vsb AUX
- Low profile 3 x 6 x 1.38 inch
- Low power consumption at standby mode
- Isolated between PE and RETURN
- Class-I design 300W @ 19V with +5Vsb AUX
- Low profile 3 x 6 x 1.38 inch
- Low power consumption at standby mode
- Isolated between PE and RETURN
- Class-I design 300W @ 12V with +5Vsb AUX
- Low profile 3 x 6 x 1.38 inch
- Low power consumption at standby mode
- Isolated between PE and RETURN
- Class-I design 250W dual outputs
- 12V @ 50W, 54V @ 200W
- For PoE application
- Dimension 4"x7.5"x1.44"
- Isolated between 12V & 54V outputs
- Isolated between PE & RETURN
- IEC 62368-1 safety standard
- Dimension 3"x5"x1.165"
- Input power less than 0.5W at 0.2W load
- 260W at 18 CFM forced air cooling or 150W at convection cooling
